ASTM + AS Viewing and Interpretation of Radiographs . Дефектоскопия . Радиография
Автор: TAFE
Жанр: Машиностроение.Сварочное производство.Контроль качества.
Формат: PDF
Качество: eBook (изначально компьютерное)
Количество страниц: 59
Описание: Ознакомительная документация по проведению радиографического контроля сварных соединений .(Американский и австралийский стандарт)
Содержит:
Проведение.
Требования к радиографическим снимкам.
Виды дефектов.
Краткий справочник
The final stage in radiographic testing is the viewing, interpretation and reporting the results of a radiographic inspection. After all, the real purpose of a radiographic inspection is to provide information about the acceptability, or otherwise, of the product being tested.
After compeleting this task, you should be able to:
• set up and check the conditions for properly viewing a radiograph
• interpret weld radiographs for defect in accordance with Australian Standards
• interpret casting radiographs in accordance with ASME and Australian Standards.
